1. Different resolution (P2.5,P3,P4,P5) and different dimensions are available;
2. 3G/4G/WIFI/USB and RJ45 etc. control;
3. Smart controller system with auto-brightness adjustment;
4. GPS real-time monitoring;
5. Cloud publishing for remote control of your multiple displays, publish your program anywhere at anytime via 3G/4G;
6. Super energy saving compare to traditional led, extending the service life of the display, protect your car battery and save cost;
7. High visible brightness even under direct sunlight;
8. Modular design of different parts so that can get it easily installed and quickly for maintenance;
9. Customized design available includes design, frame, resolution, size, and different control method options;
10.Light weight and slim design;
11.7/24 technical support.
Item | Value | |||
Pixel pitch | 2.5 | 3.3 | 4 | 5 |
Usage | Outdoor | |||
Pixel Configuration | 1R1G1B | |||
LED Encapsulation | SMD1415 | SMD1921 | SMD2727 | |
Pixel Density (dots/sqm) | 160000 | 91828 | 62500 | 40000 |
Brightness (CD/m2) | 5000~5500 | |||
Module Size(mm) | 160*160 | 320*160 | ||
Cabinet Size(mm) | 960*320 (double sided) | |||
Cabinet material | Aluminum | |||
Weight | 15KG | |||
Viewing Angle | H: 120° V: 120° | |||
Refresh Rate | 1920HZ | |||
Frame Frequency | 50 - 60Hz | |||
Working Voltage | 12V | |||
MTBF | > 10,000 hrs | |||
Lifespan | ≥ 100,000 hrs | |||
Power Consumption (Avg./Max.) | 260/850 | |||
Working Temperature / Humidity | -40℃ - +50℃ 10-90% RH |
