Features and functions
Ultra-thin design, over 97% color saturation , exquisite picture quality, low brightness and high gray, 8-levelfreely adjustable brightness;
Support USB, WIFI,4G, Lan, APP control to play;
Support multiple splicing large screen to meet more advertisements and events;
Support intelligent cluster management &control , support remote centralize management, auditing, play and control.
Support standing, wall mounted hanging and creative DIY as horizontal and vertical installation.
Plug and play, Any video automatically plays full screen, zero setting , quick and simple;
Widely used in Advertising media, Concert, TV SHOW, Super mall, Entertainment,School,Government,Trading conversation, Commodity fair,Exhibition,Cinema,News conferences, Meeting room,Airport,Hotel,Station Hall and other Public Places.
| Item | Value | ||
| Model | CDT-201 | CDT-251 | CDT-301 |
| Pixel pitch | 2 | 2.5 | 3 |
| Usage | Indoor | ||
| Pixel Configuration | 1R1G1B | ||
| LED Encapsulation | SMD1515 | SMD2121 | |
| Pixel Density (dots/sqm) | 250000 | 160000 | 111111 |
| Brightness （CD/m2） | 800 | ||
| Module Size（mm） | 320*160 | 192*192 | |
| Panel Size（mm） | 640*1920 | 576*1920 | |
| Panel material | Alumium | ||
| Panel weight | < 35KG | ||
| Viewing Angle | H: 120° V: 120° | ||
| Refresh Rate | > 1920HZ | ||
| Frame Frequency | 50 - 60Hz | ||
| Working Voltage | 220V AC±10% | ||
| MTBF | > 10,000 hrs | ||
| Lifespan | ≥ 100,000 hrs | ||
| Power Consumption (Avg./Max. W/sqm) | 320/800 | 310/780 | 270/680 |
| Working Temperature / Humidity | -20℃～45℃10～90%RH | ||
| Storage Temperature / Humidity | -25℃～50℃ 10～90%RH | ||
